HSDL-7002

IrDA, 3/16 Encode/Decode Integrated Circuit, 16-QFN, 0.46 W max, -0.5 to 7.0 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~0.10 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~0.10

PartNumber:: HSDL-7002

Brand:: Agilent Technologies - Agilent | Pack: QFN | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. NaNa's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-12

From Other Seller

Part Number:HSDL-7002
US $0.10 - 0.10
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The HSDL-7002 is an IrDA 3/16 Encode/Decode Integrated Circuit. It modulates and demodulates electrical pulses from HSDL-3201 IrDA transceiver module and other IrDA compliant transceivers. The HSDL-7002 can be used with a microcontroller/microprocessor that has a serial communication interface(UART). Prior to communication, the processor selects the transmission baud rate. Serial data is then transmitted or received at the prescribed data rate. The HSDL-7002 consists or two state machines – the SIR (Serial InfraRed) Encode and SIR Decode blocks. The HSDL-7002 also contains a sequential block Clock Divide that synthesizes the required internal signal.

Parametrics

HSDL-7002 absolute maximum ratings: (1)Storage Temperature, TS: -65 to +150 ℃; (2)Operating Temperature, TA -40 to +85 ℃; (3)Output Current, IO: -20 to 15 mA; (4)Power Dissipation, PMAX: 0.46 W max; (5)Input/Output Voltage, VI /VO -0.5 to Vcc+0.5 V; (6)Power Supply Voltage, VCC: -0.5 to 7.0 V; (7)Electrostatic Protection, VESD: 4000 V.

Features

HSDL-7002 features: (1)Fully Compliant to IrDA Physical Layer Specification 1.4 from 9.6 kbit/s to 115.2 kbit/s (SIR); (2)Interfaces with IrDA Compliant IR Transceiver; (3)Miniature Module Size with 16-pin Quad-Flat-No Lead (QFN) Package: Height: 0.8 mm; length: 4.0 mm; Depth: 4.0 mm; (4)Used in Conjunction with Standard 16550 UART; (5)Transmits/Receives either 1.63 μs or 3/16 Pulse Mode; (6)Internal or External Clock Mode; (7)Programmable Baud Rate 2.7 – 5.5 V Operation; (8)Lead Free and Green Product.
